24W RCM SAA AU adapter-SK03T

24W AUS adapter‑SK03T is a detachable‑plug power adapter, ultra‑small, lightweight and fully‑sealed for portability. Using ultrasonic lamination, 24W AUS adapter‑SK03T delivers high reliability at competitive cost. It has multi‑protections, 100‑240VAC input, CC/CV low‑noise output complying with ERP & CEC‑VI. Naturally cooled, 24W AUS adapter‑SK03T runs 0‑40℃, meets IEC/AS/NZS safety and RoHS. It supports multi‑country pins with 50,000‑hour MTBF for global applications.

24W RCM AUS adapter-SK03T Features:

1). Ultra-small size, light weight, streamline, fully sealed and easy to carry;

2). Competitive price design, high reliability,ultraonic lamination;

3). Built-in over voltage, over current and short circuit protection;

4). Input Characteristics: Voltage :100-240VAC ± 10%; Frequency: 50/60Hz; Current: 0.6A Max;

Starting Time:3s max;Inrush Current20A/240VAC Max

5). Output characteristics: constant current / constant voltage mode; high precision, low noise;Hold up time: 20mS Min;

6). Environmental: Operating temperature: 0 ℃ -40 ℃, 5% -90% RH;

Storage temperature: -20 ℃ -85 ℃, 5% -95% RH;

7). Cooling mode: natural cooling;

8). Energy efficiency accordingly: ERP / CEC-VI standard;

9). Safety standards: IEC60950-1 AS/NZS 60950.1, AS/NZS CISPR 22, AS/NZS 4665;

10).Meet ROHS standards;

11).Pin Type: UL / CCC / VDE / BS / SAA / KC / PSE;

12).MTBF: 50,000 hours;

13).Electrical characteristics: (see below sheet)
