6W Japanese PSE adapter-SK01T

6W Japan Power Adapter
This 6W Japan power adapter supports wide voltage input, meets Level VI energy efficiency standards, and features multiple safety protections. It has obtained PSE certification. With a wall-mount plug-in structure, the adapter delivers stable regulated output and low power consumption, making it suitable for powering small electronic devices in the Japanese market.

6W Japanese adapter Features:

1). Ultra-small size, light weight, streamline, fully sealed and easy to carry;

2). Competitive price design, high reliability,ultraonic lamination;

3). Built-in over voltage, over current and short circuit protection;

4). Input Characteristics: Voltage :100-240VAC ± 10%; Frequency: 50/60Hz; Current: 0.2A Max;

Starting Time:3s max;Inrush Current20A/240VAC Max

5). Output characteristics: constant current / constant voltage mode; high precision, low noise;Hold up time: 20mS Min;

6). Environmental: Operating temperature: 0 ℃ -40 ℃, 5% -90% RH;

Storage temperature: -20 ℃ -85 ℃, 5% -95% RH;

7). Cooling mode: natural cooling;

8). Energy efficiency accordingly: ERP / CEC-VI standard;

9). Safety standards: IEC60950-1, J60950-1(H22), J55022(H22), J3000(H21);

10).Meet ROHS standards;

11).Pin Type: UL / CCC / VDE / BS / SAA / KC / PSE;

12).MTBF: 50,000 hours;

13).Electrical characteristics: (see below sheet)
