6W Korea adapter-SK01T

6W Korea Power Adapter
This 6W Korea power adapter supports wide voltage input, meets Level VI energy efficiency standards, and is equipped with multiple safety protections. It has obtained KC certification. Featuring a wall-mount plug-in structure, the adapter delivers reliable regulated output and low standby power consumption, making it suitable for various small electronic devices in the Korean market.

6W Korea adapter Features:

1). Ultra-small size, light weight, streamline, fully sealed and easy to carry;

2). Competitive price design, high reliability,ultraonic lamination;

3). Built-in over voltage, over current and short circuit protection;

4). Input Characteristics: Voltage :100-240VAC ± 10%; Frequency: 50/60Hz; Current: 0.2A Max;

Starting Time:3s max;Inrush Current:20A/240VAC Max

5). Output characteristics: constant current / constant voltage mode; high precision, low noise;Hold up time: 20mS Min;

6). Environmental: Operating temperature: 0 ℃ -40 ℃, 5% -90% RH;

Storage temperature: -20 ℃ -85 ℃, 5% -95% RH;

7). Cooling mode: natural cooling;

8). Energy efficiency accordingly: ERP / CEC-VI standard;

9). Safety standards: IEC 60950-1, K60950-1, KN22

10).Meet ROHS standards;

11).Pin Type: UL / CCC / VDE / BS / SAA / KC / PSE;

12).MTBF: 50,000 hours;

13).Electrical characteristics: (see below sheet)
