Abstract

High-power desktop Silicon Carbide Power Adapter supports wide-range constant-power output for bench instruments and industrial peripherals. Silicon Carbide Power Adapter achieves peak full-load efficiency of 95.6% and 1.6W/cm³ power density at 125kHz. Silicon Carbide Power Adapter uses constant-power loop to maintain fixed power across multiple output voltages.

1. Input & Output Electrical Parameters

Desktop high-power Silicon Carbide Power Adapter accepts 85–264VAC input, 50/60Hz, max input current 2.4A. Silicon Carbide Power Adapter delivers constant power 120W across 20~48V, output current adjusts dynamically with voltage. Silicon Carbide Power Adapter peak full-load efficiency 95.6%, PF≥0.97, switching frequency 125kHz. Thanks to low-loss SiC, Silicon Carbide Power Adapter maintains high efficiency across the whole constant-power range without sharp drop at low voltage high current. Silicon Carbide Power Adapter peak ripple ≤55mV, ±2% tolerance for bench test instruments and high-power peripherals.

2. Constant-Power Loop Control

Silicon Carbide Power Adapter integrates constant-power loop: current rises automatically as output voltage drops to keep power fixed. The constant-power range of Silicon Carbide Power Adapter spans 20V to 48V for variable loads. Silicon power supplies suffer heavy losses and thermal derating under low voltage high current. Silicon Carbide Power Adapter maintains full power with minimal derating. Fast control loop keeps power fluctuation below 5% during load transients.

3. Thermal Design & Environmental Resistance

Silicon Carbide Power Adapter operating temperature -10℃~+50℃, storage -30℃~+85℃, humidity 5~95% non-condensing. Continuous full-power operation at 45℃ ambient gives case temperature rise of 60℃. Silicon Carbide Power Adapter uses optimized thermal conduction to spread heat to enclosure without cooling fans, eliminating fan noise and fan failure risk. Fanless structure also prevents dust ingress and extends service life.

4. Safety Protection & Certifications

Silicon Carbide Power Adapter includes OVP, OCP, SCP, OTP, UVLO plus dual constant-power current limiting protection. Silicon Carbide Power Adapter hipot rating 3000VAC and complies with UL62368. Certifications include UL62368, CE, FCC, UKCA, KC for worldwide sales. Silicon Carbide Power Adapter meets EN55032 Class B EMC for lab test equipment. Silicon Carbide Power Adapter MTBF≥54,000 hours.

Summary

Fanless high-power desktop Silicon Carbide Power Adapter provides wide-voltage constant power for laboratory and high-power peripherals. Contact Simsukian for samples and custom Silicon Carbide Power Adapter solutions.
