Abstract

A PD GaN fast charger integrates complete protection circuits to handle short-circuit, over-voltage and over-current faults. After fault detection, the PD GaN fast charger rapidly cuts output to protect end devices. This PD GaN fast charger covers protection thresholds, response speed and auto-recovery logic. Multi-layer safeguards reduce fire and hardware damage risks.

1. Over-Voltage Protection OVP

When output exceeds threshold, OVP of the PD GaN fast charger triggers immediately. OVP level of the PD GaN fast charger is typically 110%~120% of each rated voltage profile. Response of the PD GaN fast charger operates in microseconds to avoid high-voltage stress on loads.

2. Over-Current OCP and Short-Circuit SCP

When output current exceeds limit, OCP of the PD GaN fast charger activates for current limiting. On output short-circuit, SCP of the PD GaN fast charger latches output off. After fault removal, selected models of the PD GaN fast charger support auto-retry recovery.

3. Over-Temperature Protection OTP

The PD GaN fast charger uses NTC thermistors for real-time temperature monitoring. When junction temperature exceeds threshold, the PD GaN fast charger first derates power and shuts down in severe overheat. After cooling, the PD GaN fast charger can restore output automatically.

4. CC Communication Fault Protection

When CC pin communication fails, the PD GaN fast charger locks to safe 5V output. The PD GaN fast charger prevents accidental high-voltage negotiation for non-PD legacy devices. Communication fault protection is a unique safety feature of the PD GaN fast charger.

5. Safety Certification Requirements

All protection functions of the PD GaN fast charger must pass IEC62368 safety tests. Failed protection mechanisms cause certification rejection and block export.

Conclusion

Multi-layer protection ensures charging safety for the PD GaN fast charger. To test protection thresholds and fault response of a PD GaN fast charger, contact Simsukian for test documentation.

References

1. USB-IF USB Power Delivery Specification

2. IEC 62680-1-2 USB PD International Standard

3. IEC 62368-1 AV and ICT Equipment Safety Standard
